3 Ton Chain Pulley Block

Weight

One of the lightest in the world compared to capacity.

Head Room

Very low compare to capacity

Body

Made of Pressed steel with weldless construction

Hooks

High Tensile Forged Steel Hooks conforming to IS:8610 which rotate and swivel freely.

Load Wheel

Made of Steel Casting suitably Heat treated and mounted on Needle Bearings for smooth operation.

Load Chain

Grade 80 IS:6216 Alloy Steel Link Chain.

Hand Chain

6 mm dia Gr.30-IS:2429 Pt (I)

Chain Wheels

Hand Chain Wheels are made of Pressed Steel and provided with integrated cover cum Guide preventing Chain fouling.

Brake

Multiple Threaded Screw and Friction-Disc type self-actuating Load Brake ensures complete safety.

Gears

All load bearing gears are made from special Alloy Steel, precision machine cut, case hardened and treated for rust prevention.

Guarantee

A Guarantee is provided for the repair and replacement ( F. O. R Faridabad basis ) of any part which proves defective in material or workmanship within one year of sale

Capacity

Up to 30 tons

Capacity (te)

1

2

3

5

7.5

10

12.5

15

20

25

Standard Lift

3 m

3 m

3 m

3 m

3 m

3 m

3 m

3 m

3 m

3 m

Weight at 3 metre Lift. (Approx) (Kg)

18

26

34

46

105

120

140

250

300

350

Pull on hand chain. (Approx) (Kg)

25

30

30

35

45

40

50

45+45

40+40

50+50

Number of falls

1

1

2

3

2

3

4

2 + 2

3 + 3

4 + 4
